Tinned Cable Single Core 6mm2 Per Metre

Tinned Cable Single Core 6mm2 Per Metre

OceanFlex


Price:  £1.75    (£1.46 Exc. VAT)

Low voltage, high performance wiring cable.

We're currently unable to show live stock information on our website, so if you need delivery fast we strongly recommend checking availability first. Simply fill out the form below and we'll get back to you, or call us on +44 (0)1243 375774 for an immediate answer.

*
*
*
Please add the two numbers

Be the first to Write a Review for this item!

Product Information

Tinned Cable Features

  • Tinned copper conductors provide excellent resistance to corrosion
  • Good resistance to petrol, diesel, lubricating oils, diluted acid and moisture
  • Hard grade PVC insulation offers good resistance to abrasion and cut though
  • Suitable for use at temperatures -40ºC to +105ºC with excursions up to 120ºC
  • Suitable for 12V and 24V systems (maximum 60V)
  • Manufactured in accordance with ISO 6722-1:2011 (Class B)
  • Cables are printed with the specification on the insulation


Tinned Cable Specifications

Conductor Cross Section Conductor Specification Current Rating Overall Cable Diameter Resistance per M at 20°C
1.5 mm2 21/0.30 mm 21.0 amps 2.4 mm 0.0130 ohms
2.5 mm2 35/0.30 mm 29.0 amps 3.0 mm 0.00782 ohms
4.0 mm2 56/0.30 mm 39.0 amps 3.7 mm 0.00485 ohms
6.0 mm2 84/0.30 mm 50.0 amps 4.3 mm 0.00323 ohms
10.0 mm2 80/0.40 mm 70.0 amps 6.0 mm 0.00185 ohms
